Description

Technical Specifications :-

Silent Features :-

• Self Test System

• Auto/Manual selection modes

• Air/Skin servo controlled system

• Double Digital Display for ACTUAL & SET temperature

• °C/°F settings

• Heater power indicator

• Feather touch keys for easy operation

• Key pad lock facility

• AIR/SKIN/MANUAL Modes

• Power failure alarm – Fault indication alarms for 1°C low/high, probe failures, high temperature cutoff, system failure, heater failure, etc.

Baby & Air Probe :-

Baby & Air probe is made of highly sensitive sensor and is interchangeable. Field calibration is taken care of by software. The probe is made up of silicon sheathed cable, which allows easy cleaning.

Observation Lamp :-

LED-based observation light focuses on any area on the bed.

Heater :-

Single element CE-approved ceramic heater placed in a parabolic reflector.

Baby Trolley :-

An attachable baby trolley which consists of a large baby tray. It is made of mild steel frame with three side acrylic collapsible walls. Trendelenburg & Fowler system provided.

Physical Parameters :-

• Baby Tray
  Length : 700mm
  Width : 500mm
  Mattress Thickness : 25mm

• Overall
  Length : 900mm
  Width : 800mm
  Height : 1900mm
  Working level from ground : 900mm
  Weight Approx. : 40kg
  Castors : 75mm with 2 brake wheels and 2 non-brake wheels

Recommended Environmental Specifications :-

• Operating temperature range : 20°C to 33°C

• Storage temperature range : -25°C to 60°C

• Operating humidity range : 0 – 100% RH

Skin / Air Temperature Probe :-

• Range : 28°C to 38°C

• Accuracy : +/- 0.2°C within range

• Resolution : 0.1°C

• Probe Interchangeability : +/- 0.2°C (Servo)

• Heater output controllable : From 0 to 100% in Manual mode (continuously variable)

Electrical Specifications :-

• Electrical Supply : 230 V ± 10%, 50 Hz

• Power consumption with Heater at max. output : 650W

Other Facilities :-

• I.V. stand provided

• Monitor tray provided
